Flat Multicore
In the demanding world of modern electrical applications, where space is a premium and reliability is non-negotiable, the APAR Mahashakti Flat Multicore Cable emerges as a technologically advanced and efficient solution. This high-performance electrical cable, featuring a unique flat arrangement of multiple cores, is specifically engineered to deliver unmatched compactness and ease of installation, making it the ideal flat flexible cable for tight spaces and dynamic systems. Constructed with a commitment to quality and utilizing advanced manufacturing techniques, our flat multicore cable ensures exceptional electrical conductivity and superior durability for diverse electrical applications.
Maximum Operating Temperature Up to 70°C
Ensuring stable performance in varied environmental conditions, this high-temperature flat cable maintains integrity and efficiency where conventional cables may falter.
High Operating Life of the Cables
Designed for longevity and consistent performance, our cables reduce downtime and replacement costs, offering an extended service life electrical cable for critical applications.
Features & Advantages
From the precision of robotics cables and automation cables to the intricate demands of instrumentation and control systems, the APAR Mahashakti Flat Multicore Cable provides reliable power and signal transmission. Its inherent resistance to harsh environments and various stress factors guarantees a robust and high operating life of cables, significantly minimizing maintenance requirements for both indoor and outdoor installations. Experience the APAR advantage with a versatile cable solution built for the future.
The APAR Mahashakti Flat Multicore Cable is meticulously crafted to ensure excellent electrical conductivity and long-term reliability. Our commitment to high-quality materials starts with bright annealed copper conductors, conforming to IS 8130 standards, ensuring maximum current carrying capacity with minimal energy loss. The flat geometry inherently provides superior heat dissipation, allowing the cable to operate efficiently even in high-density installations without excessive temperature build-up, a significant advantage over bulky round cables.
This design also contributes to reduced electromagnetic interference (EMI) and crosstalk between cores, crucial for maintaining signal integrity in sensitive instrumentation and control systems. The APAR Mahashakti Flat Multicore Cable is a testament to precision engineering, offering a robust solution that is compact, efficient, and built to last.
Increased Flexibility
Easily navigable and adaptable, the flat flexible multicore cable excels in dynamic applications such as flat cables for robotics and drag chain cables, where continuous movement is essential.
Specially In-House Formulated XLPO Compound
Utilizing our proprietary XLPO insulated cable material, this compound provides superior thermal, electrical, and mechanical properties, making it an advanced and halogen-free flat cable option.
Technical Characteristics & Standards
| Technical Characteristics & Standards | |||||
|---|---|---|---|---|---|
| 3 Core Flat, XLPO insulated and special Elastomer sheathed cable | |||||
| Nominal Area of Copper Conductor (Sq.mm) |
Number of Wire/ Diameter of Wire (No./Dia.mm) |
Thickness of Insulation (Nominal) (mm) |
Thickness of Outer sheath (Nominal) (mm) |
Approx Overall Diameter (mm) |
Conductor Resistance (Max) per km @20° C (Ohms) |
| 1.5 | 30/0.26 | 0.65 | 0.95 | 10.30 x 4.90 | 13.3 |
| 2.5 | 50/0.26 | 0.75 | 1.05 | 12.6 X 5.8 | 7.98 |
| 4 | 56/0.31 | 0.85 | 1.1 | 14.8 x 6.60 | 4.95 |
| 6 | 84/0.31 | 0.85 | 1.3 | 16.95 x 7.4 | 3.3 |
| 10 | 140/0.31 | 1.2 | 1.7 | 24.15 x 10.15 | 1.91 |
| 16 | 226/0.31 | 1.05 | 1.6 | 26.2 X 10.7 | 1.21 |
| 25 | 354/0.31 | 1.4 | 2 | 32.8 X 13.6 | 0.78 |
| 35 | 495/0.31 | 1.4 | 2.25 | 37.4 X 15.8 | 0.554 |
| 50 | 703/0.31 | 1.5 | 2.3 | 42.6 X 17.4 | 0.386 |
- Core: 3 Core
- Insulation: XLPO
- Length: 500/1000 m
- Colour: Grey
*Also available in XLPE and Rubber insulation
*Also available in flexible aluminium conductor
Related Products
Frequently asked questions
What is a flat multicore cable, and why choose it over a round cable?
A flat multicore cable features multiple conductors arranged side-by-side within a flat sheath. This design offers superior flexibility, easier routing in tight spaces, better heat dissipation, and reduced electromagnetic interference compared to traditional round cables. It’s often chosen for applications like flat cables for automation and robotics where space and dynamic movement are critical.
What does XLPO insulation offer, and is it a safer option?
XLPO (Cross-linked Polyolefin) is a specially formulated, advanced insulation material known for its excellent thermal, electrical, and mechanical properties. Our in-house formulated XLPO compound offers superior fire retardancy, low smoke emission, and is often halogen-free, making it a safer and more environmentally friendly alternative to PVC, especially in enclosed environments.
Can this cable be used for outdoor installations?
Yes, the APAR Mahashakti Flat Multicore Cable is constructed with high-quality materials and designed for resistance to harsh environments and various stress factors. This makes it a reliable choice for both indoor and outdoor installations, minimizing maintenance requirements and ensuring consistent performance.
Where are APAR Mahashakti Flat Multicore Cables commonly used?
These versatile cables find extensive use in automation cables, robotics cables, instrumentation, and control systems for power and signal transmission. They are particularly ideal for space-limited situations and applications requiring increased flexibility, such as crane control cables, lift cables, and drag chain applications.
